Series 115
Dual-in-line sockets very low profile /
ultra low profile / open frame
Solder tail
Preci-Dip “Very low / Ultra
low profile” sockets have
specially designed con-
tacts for reduced socket
height above PCB
Insertion characteristics:
4-finger standard
(very low)
4-finger short (ultra low)
Platings
Sleeve
Clip
Pin
91
5 mm Sn Pb
0.25 mm Au
93
5 mm Sn Pb
0.75 mm Au
97
5 mm Sn Pb
Goldflash
99
5 mm Sn Pb
5 mm Sn Pb
Ordering information
For standard version (ultra low) (Fig. 1) see table
Option:
Very low version (Fig. 2) is optional; change suffix 003 to 001.
Insulator body dimensions see page 50 Fig. 1 to 28. Same num-
ber of poles as standard series 110.
6
115-91-306-41-003
115-93-306-41-003
115-97-306-41-003
115-99-306-41-003
Fig. 50
7.6
7.62
10.1
8
115-91-308-41-003
115-93-308-41-003
115-97-308-41-003
115-99-308-41-003
Fig. 51
10.1
7.62
10.1
10
115-91-310-41-003
115-93-310-41-003
115-97-310-41-003
115-99-310-41-003
aFig. 51a
12.6
7.62
10.1
14
115-91-314-41-003
115-93-314-41-003
115-97-314-41-003
115-99-314-41-003
Fig. 52
17.7
7.62
10.1
16
115-91-316-41-003
115-93-316-41-003
115-97-316-41-003
115-99-316-41-003
Fig. 53
20.3
7.62
10.1
18
115-91-318-41-003
115-93-318-41-003
115-97-318-41-003
115-99-318-41-003
Fig. 54
22.8
7.62
10.1
20
115-91-320-41-003
115-93-320-41-003
115-97-320-41-003
115-99-320-41-003
Fig. 55
25.3
7.62
10.1
22
115-91-322-41-003
115-93-322-41-003
115-97-322-41-003
115-99-322-41-003
Fig. 56
27.8
7.62
10.1
24
115-91-324-41-003
115-93-324-41-003
115-97-324-41-003
115-99-324-41-003
Fig. 57
30.4
7.62
10.1
28
115-91-328-41-003
115-93-328-41-003
115-97-328-41-003
115-99-328-41-003
Fig. 58
35.5
7.62
10.1
20
115-91-420-41-003
115-93-420-41-003
115-97-420-41-003
115-99-420-41-003
Fig. 59
22
115-91-422-41-003
115-93-422-41-003
115-97-422-41-003
115-99-422-41-003
Fig. 60
27.8
10.16
12.6
24
115-91-424-41-003
115-93-424-41-003
115-97-424-41-003
115-99-424-41-003
Fig. 61
30.4
10.16
12.6
28
115-91-428-41-003
115-93-428-41-003
115-97-428-41-003
115-99-428-41-003
Fig. 62
35.5
10.16
12.6
24
115-91-624-41-003
115-93-624-41-003
115-97-624-41-003
115-99-624-41-003
Fig. 63
30.4
15.24
17.7
28
115-91-628-41-003
115-93-628-41-003
115-97-628-41-003
115-99-628-41-003
Fig. 64
35.5
15.24
17.7
32
115-91-632-41-003
115-93-632-41-003
115-97-632-41-003
115-99-632-41-003
Fig. 65
40.6
15.24
17.7
36
115-91-636-41-003
115-93-636-41-003
115-97-636-41-003
115-99-636-41-003
Fig. 66
45.7
15.24
17.7
40
115-91-640-41-003
115-93-640-41-003
115-97-640-41-003
115-99-640-41-003
Fig. 67
50.6
15.24
17.7
48
115-91-648-41-003
115-93-648-41-003
115-97-648-41-003
115-99-648-41-003
Fig. 68
60.9
15.24
17.7
50
115-91-650-41-003
115-93-650-41-003
115-97-650-41-003
115-99-650-41-003
Fig. 69
63.5
15.24
17.7
No.
Insulator
of
Order Codes
dimen-
poles
sions
Plating 91
Plating 93
Plating 97
Plating 99
See
A
B
C
page 51
B
B
Fig. 1
Fig. 2 B
