Series 117 / 217
Shrinkdip sockets
Open and closed frame
Solder tail
High density Dual-in-line
sockets for devices fea-
turing 0.07¢¢ (1.778 mm)
lead spacing. Four-finger
beryllium copper contact
meets high vibration and
shock requirements
Insertion characteristics:
4-finger standard
Platings
Sleeve
Clip
Pin
91
5 mm Sn Pb
0.25 mm Au
93
5 mm Sn Pb
0.75 mm Au
97
5 mm Sn Pb
Goldflash
99
5 mm Sn Pb
5 mm Sn Pb
Ordering information
For complete part number see Order Codes list below
Open frame 117
16
117-91-316-41-005
117-93-316-41-005
117-97-316-41-005
117-99-316-41-005
Fig. 70
14.60
7.62
10.16
28
117-91-428-41-005
117-93-428-41-005
117-97-428-41-005
117-99-428-41-005
Fig. 71
25.20
10.16
12.70
30
117-91-430-41-005
117-93-430-41-005
117-97-430-41-005
117-99-430-41-005
aFig. 71a
27.00
10.16
12.70
32
117-91-432-41-005
117-93-432-41-005
117-97-432-41-005
117-99-432-41-005
bFig. 71b 28.80 10.16 12.70
48
117-91-448-41-005
117-93-448-41-005
117-97-448-41-005
117-99-448-41-005
Fig. 72
43.00
10.16
12.70
20
117-91-620-41-005
117-93-620-41-005
117-97-620-41-005
117-99-620-41-005
Fig. 81
18.10
15.24
17.78
24
117-91-624-41-005
117-93-624-41-005
117-97-624-41-005
117-99-624-41-005
Fig. 82
21.55
15.24
17.64
28
117-91-628-41-005
117-93-628-41-005
117-97-628-41-005
117-99-628-41-005
Fig. 73
25.20
15.24
17.78
40
117-91-640-41-005
117-93-640-41-005
117-97-640-41-005
117-99-640-41-005
Fig. 74
35.90
15.24
17.78
42
117-91-642-41-005
117-93-642-41-005
117-97-642-41-005
117-99-642-41-005
Fig. 75
37.70
15.24
17.78
48
117-91-648-41-005
117-93-648-41-005
117-97-648-41-005
117-99-648-41-005
Fig. 76
43.10
15.24
17.78
52
117-91-652-41-005
117-93-652-41-005
117-97-652-41-005
117-99-652-41-005
Fig. 77
46.60
15.24
17.78
56
117-91-656-41-005
117-93-656-41-005
117-97-656-41-005
117-99-656-41-005
aFig. 77a 50.00 15.24 17.78
64
117-91-664-41-005
117-93-664-41-005
117-97-664-41-005
117-99-664-41-005
Fig. 78
57.20
15.24
17.78
68
117-91-668-41-005
117-93-668-41-005
117-97-668-41-005
117-99-668-41-005
Fig. 79
60.80
15.24
17.78
64
117-91-764-41-005
117-93-764-41-005
117-97-764-41-005
117-99-764-41-005
Fig. 80
57.40
19.05
21.59
Closed frame 217
64
217-91-764-41-005
217-93-764-41-005
217-97-764-41-005
217-99-764-41-005
Fig. 90
57.40
19.05
21.59
No.
Insulator
of
Order Codes
dimen-
poles
sions
Plating 91
Plating 93
Plating 97
Plating 99
See
A
B
C
page 52
B
