Series 210
Dual-in-line sockets
Closed frame
Solder tail
Closed frame “solid” in-
sulator withstands high
mechanical impact. Low
profile
Available with series 10
standard pins, other types
on request
Insertion characteristics:
4-finger standard
Platings
Sleeve
Clip
Pin
91
5 mm Sn Pb
0.25 mm Au
93
5 mm Sn Pb
0.75 mm Au
97
5 mm Sn Pb
Goldflash
99
5 mm Sn Pb
5 mm Sn Pb
Ordering information
For complete part number see Order Codes list below
6
210-91-306-41-001
210-93-306-41-001
210-97-306-41-001
210-99-306-41-001
Fig. 30
7.6
7.62
10.10
8
210-91-308-41-001
210-93-308-41-001
210-97-308-41-001
210-99-308-41-001
Fig. 31
10.1
7.62
10.10
10
210-91-310-41-001
210-93-310-41-001
210-97-310-41-001
210-99-310-41-001
Fig. 32
12.6
7.62
10.10
14
210-91-314-41-001
210-93-314-41-001
210-97-314-41-001
210-99-314-41-001
Fig. 33
17.7
7.62
10.10
16
210-91-316-41-001
210-93-316-41-001
210-97-316-41-001
210-99-316-41-001
Fig. 34
20.3
7.62
10.10
18
210-91-318-41-001
210-93-318-41-001
210-97-318-41-001
210-99-318-41-001
Fig. 35
22.8
7.62
10.10
20
210-91-320-41-001
210-93-320-41-001
210-97-320-41-001
210-99-320-41-001
Fig. 36
25.3
7.62
10.10
24
210-91-324-41-001
210-93-324-41-001
210-97-324-41-001
210-99-324-41-001
Fig. 37
30.4
7.62
10.10
22
210-91-422-41-001
210-93-422-41-001
210-97-422-41-001
210-99-422-41-001
Fig. 38
27.8
10.16
12.60
24
210-91-424-41-001
210-93-424-41-001
210-97-424-41-001
210-99-424-41-001
Fig. 39
30.4
10.16
12.60
24
210-91-624-41-001
210-93-624-41-001
210-97-624-41-001
210-99-624-41-001
Fig. 40
30.4
15.24
17.70
28
210-91-628-41-001
210-93-628-41-001
210-97-628-41-001
210-99-628-41-001
Fig. 41
35.5
15.24
17.70
32
210-91-632-41-001
210-93-632-41-001
210-97-632-41-001
210-99-632-41-001
Fig. 42
40.6
15.24
17.70
36
210-91-636-41-001
210-93-636-41-001
210-97-636-41-001
210-99-636-41-001
Fig. 43
45.7
15.24
17.70
40
210-91-640-41-001
210-93-640-41-001
210-97-640-41-001
210-99-640-41-001
Fig. 44
50.6
15.24
17.70
48
210-91-648-41-001
210-93-648-41-001
210-97-648-41-001
210-99-648-41-001
Fig. 45
61.0
15.24
17.64
No.
Insulator
of
Order Codes
dimen-
poles
sions
Plating 91
Plating 93
Plating 97
Plating 99
See
A
B
C
page 51
B
B
B
B
