Series 299
Dual-in-line sockets / right angle version
Closed frame
Solder tail
Series 299 Dil sockets
with closed frame insula-
tor are designed for com-
ponents to be mounted
perpendicularly to the
PCB, such as LED displays
Right angle solder-tails
are available with either
7.62 mm (standard) or
2.54 mm row spacing
Insertion characteristics:
4-finger standard
Platings
Sleeve
Clip
Pin
93
5 mm Sn Pb
0.75 mm Au
91
5 mm Sn Pb
0.25 mm Au
Ordering information
For complete part number see Order Codes list below
6
299-93-306-10-001
299-93-306-11-001
299-91-306-10-001
299-91-306-11-001
7.6
7.62
10.1
8
299-93-308-10-001
299-93-308-11-001
299-91-308-10-001
299-91-308-11-001
10.1
7.62
10.1
10
299-93-310-10-001
299-93-310-11-001
299-91-310-10-001
299-91-310-11-001
12.6
7.62
10.1
12
299-93-312-10-001
299-93-312-11-001
299-91-312-10-001
299-91-312-11-001
15.2
7.62
10.1
14
299-93-314-10-001
299-93-314-11-001
299-91-314-10-001
299-91-314-11-001
17.7
7.62
10.1
16
299-93-316-10-001
299-93-316-11-001
299-91-316-10-001
299-91-316-11-001
20.3
7.62
10.1
18
299-93-318-10-001
299-93-318-11-001
299-91-318-10-001
299-91-318-11-001
22.8
7.62
10.1
20
299-93-320-10-001
299-93-320-11-001
299-91-320-10-001
299-91-320-11-001
25.3
7.62
10.1
24
299-93-324-10-001
299-93-324-11-001
299-91-324-10-001
299-91-324-11-001
30.4
7.62
10.1
8
299-93-608-10-002
299-91-608-10-002
10.1
15.24
17.7
10
299-93-610-10-002
299-91-610-10-002
12.6
15.24
17.7
12
299-93-612-10-002
299-91-612-10-002
15.2
15.24
17.7
14
299-93-614-10-002
299-91-614-10-002
17.7
15.24
17.7
16
299-93-616-10-002
299-91-616-10-002
20.1
15.24
17.7
18
299-93-618-10-002
299-91-618-10-002
22.8
15.24
17.7
20
299-93-620-10-002
299-91-620-10-002
25.3
15.24
17.7
22
299-93-622-10-002
299-91-622-10-002
27.8
15.24
17.7
24
299-93-624-10-002
299-91-624-10-002
30.4
15.24
17.7
26
299-93-626-10-002
299-91-626-10-002
33.0
15.24
17.7
28
299-93-628-10-002
299-91-628-10-002
35.5
15.24
17.7
30
299-93-630-10-002
299-91-630-10-002
38.0
15.24
17.7
32
299-93-632-10-002
299-91-632-10-002
40.6
15.24
17.7
36
299-93-636-10-002
299-91-636-10-002
45.7
15.24
17.7
40
299-93-640-10-002
299-91-640-10-002
50.6
15.24
17.7
No.
Insulator
of
Order Codes
dimen-
poles
sions
Plating 93
Plating 93
Plating 91
Plating 91
See
A
B
C
page 51
E = 7.62
E = 2.54
E = 7.62
E = 2.54
B
B
B
B
